1. Product Overview

The HPIA4020 series SMD power inductor sets new standards for compact, high-performance energy storage in modern electronics. Manufactured by Hongda Capacitors, this inductor combines precision engineering with robust materials to deliver optimal performance in demanding applications. Its model designation—e.g., HPIA4020-2R2M-LF—encodes key specifications:

• ① Product Symbol: SMD power inductor
• ② Dimensions: 4.0×4.0×2.0mm
• ③ Inductance: 2.2μH (2R2), with options for 10μH (100) or 100μH (101)
• ④ Tolerance: ±20% (M) or ±30% (N)
• ⑤ Lead-Free: Compliant with environmental standards.

2. Key Technical Parameters

3. Technical Advantages

3.1 Compact Design with High Power Density

The 4.0×4.0×2.0mm form factor ensures space-saving integration, while the mixed alloy core material enhances magnetic permeability, minimizing energy loss.

3.2 Superior Electrical Performance

• Low DCR: Reduces power dissipation, improving efficiency in high-current circuits.
• High Saturation Current: Maintains inductance stability under heavy loads, critical for DC-DC converters.
• Wide Temperature Range: Operates reliably in extreme environments, from automotive engines to industrial machinery.

3.3 Lead-Free and RoHS Compliant

Meets global environmental standards, ideal for eco-friendly device designs.

4. Reliability and Testing

The HPIA4020 undergoes rigorous testing to ensure durability:

5. Applications

Perfect for:

• Consumer Electronics: Smartphones, laptops, and wearables requiring compact power solutions.
• Automotive Systems: Engine control units, LED lighting, and infotainment systems which are in Non-critical safety parts
• Industrial Equipment: Motor drives, renewable energy converters, and robotics.

6. Packaging and Storage

• Packaging: 2000 PCS/reel, tape-and-reel format for automated assembly.
• Storage: -10°C to +35°C, <70% RH, in airtight packaging to prevent oxidation.

Conclusion
The HPIA4020 SMD power inductors combine precision, durability, and efficiency, making it an indispensable component for modern electronic designs. For inquiries, contact emily@hongdacap.com.hk or visit www.hongdacap.com.hk.
